Size

60x60x15 mm

Mounting hole spacing

50x50 mm

Connector & pin-configuration

3-pin

Cable length

20cm + 30cm NA-EC1 extension cable

Bearing

SSO2

Blade geometry

A-Series with Flow Acceleration Channels

Frame technology

AAO (Advanced Acoustic Optimisation)

Material

Fibre-glass reinforced PBT

Rotational speed (+/- 10%)

3500 RPM

Rotational speed with L.N.A. (+/- 10%)

3050 RPM

Rotational Speed with U.L.N.A. (+/- 10%)

2250 RPM

Airflow

23.4 m³/h

Airflow with L.N.A.

20.1 m³/h

Airflow with U.L.N.A.

14.5 m³/h

Acoustical noise

19,8 dB(A)

Acoustical noise with L.N.A.

16.5 dB(A)

Acoustical noise with U.L.N.A.

7.8 dB(A)

Static pressure

2.43 mm H₂O

Static pressure with L.N.A.

1.79 mm H₂O

Static pressure with U.L.N.A.

0.98 mm H₂O

Input power (max.)

1.02 W

Max. input current

0.085 A

Operating voltage

12 V

MTTF

> 150.000 h

Scope of delivery

4x NA-AV2 anti-vibration mounts

NA-EC2 30cm extension cable

NA-AC1 3:4-pin adaptor cable

NA-RC15 Low-Noise Adaptor (L.N.A.)

NA-RC13 Ultra-Low-Noise Adaptor (U.L.N.A)

Fan screws
