Moza HBP Handbrake

MOZA HBP Handbrake

Key Features

- Aeroplane Grade Aluminum
- 16 Bit High Precision Position Sensor
- Pressure and Travel Adjustable
- Dual Mode and Multi-Angle Adjustable
- USB connection to PC

Aviation Grade Aluminum Body
The whole body is CNC machined using aviation-grade aluminum with an anodized finish. It is wear-resistant, sturdy, and durable.

16-bit High Precision Angle Sensor
The MOZA HBP handbrake adopts a non-contact 16-bit high precision angle sensor providing a long maintenance-free life.

Adjustable Angles
A horizontally or vertically mounted lever simulates both road and race cars, angles are adjustable according to personal needs.

Adjustable Brake Force
Adjust the rebound strength and brake travel by replacing springs.

Adjusting the Stop Position
Changing the stop position according to personal needs

Direct Connection to the PC or Wheelbase
The MOZA HBP handbrake can be connected to the PC directly or to MOZA wheelbase with a handbrake port.

Easy to Mount
The MOZA HBP handbrake is ergonomically and beautifully engineered. It can be easily mounted on most racing rigs. In addition, we will offer optional table clamps for users without an entire rig.

Easy to Fix
The MOZA HBP handbrake is ergonomically and beautifully engineered. It can be easily mounted on most racing rigs. In addition, we will offer optional table clamps for users without an entire rig.

Product Specs

• Material: Aluminum
• Dimension: 153* 68.3* • 365.5mm
• Adjustable resistance: supported
• Horizontal lever mount: supported
• Side-mount: optional
• Bolt pattern: M6

Weight

0.7Kg

What's in the Box

Handbrake base
Handbrake lever
1 * Philips screwdriver
1 * Flathead screwdriver
1 * Spring (blue color)
2 * Hex screws
2 * data cables - USB-b(1.8m) / RJ45 (2m)
2 * hex screws (come with flat pads, spring pads, and nuts)
2 * umbrella head screws (come with flat pads)
3* Allen wrenches
1*Damper
2*Damper spacers
